Cesurbend PBM-32 E Pipe and Tube Bending Machine
Quaternary Adjustable Gauge Distance Bracket
7″Color Touchscreen Display
5 sequential bending possibilities
100 program memory capacity programming
PLC Control Schneider
| Technical information | |
| Model | PBM-32 E |
| Max. Pipe Diameter | 32 |
| Max. Wall Thickness (mm) | 3 |
| Max. Bending Radius (mm) | 275 |
| Max. Bending Angle (°) | 190 |
| Bending Speed (rev/min) | 8,5 |
| Hydraulic Engine Power (kW) | 1,5 |
| Bending Engine Power (kW) | 2,2 |
| Machine Weight (kg) | 400 |
| Machine Width (mm) | 1000 |
| Machine Length (mm) | 2000 |
| Machine Height (mm) | 1050 |
